Speciality Valve is the best Check Valve Manufacturer in India. We supply to West Bengal, Haryana and Punjab. A check valve, also known as a non-return valve, one-way valve, or clack valve, is a mechanical device used in various fluid systems to allow the flow of fluid in one direction while preventing reverse flow. It is an essential component in pipelines, plumbing systems, and machinery where controlling the direction of fluid flow is important. Unlike other types of valves that regulate flow direction or pressure, check valves are designed to allow fluid to flow in only one direction while preventing reverse flow.
The working principle of a check valve is relatively simple. It consists of a valve body with an inlet and an outlet, and a movable component, such as a disc, flap, or ball, which is positioned inside the valve. This movable component is designed to allow fluid to pass through the valve in one direction while blocking flow in the opposite direction. When fluid flows in the desired direction, it exerts pressure on the movable component, causing it to move away from the valve seat and allowing fluid to pass through the valve unrestricted. However, if the fluid tries to flow in the opposite direction, the pressure from the fluid pushes the movable component against the valve seat, creating a seal that prevents reverse flow.
We manufacture Check valve in various designs, but their main principle of operation remains the same.

Parts:
1.Body or Casing
2.Inlet Port
3.Outlet Port
4.Valve Disc or Flap
5.Seat
6.Spring
7.Hinge
8.Guides and Bearings
9.Retainer or Cap
10.Diaphragm

Types:
1.Swing Check Valve
2.Lift Check Valve
3.Dual Plate Check Valve
4.Single Plate Check Valve
5.Ball Check Valve
6.Tilting Disc Check Valve
7.Piston Check Valve
8.Non Slam Swing Check Valve
9.Foot Check Valve
10.Pressure Seal Check Valve

Advantages:
1.Preventing Backflow
2.Simple and Reliable
3.Low Resistance
4.Quick Closure
5.No External Power Required
6.Wide Range of Materials
7.Diverse Applications
8.Reduced Energy Consumption
9.Cost-Effective
10.Safety

Industries:
1.Water and Wastewater Treatment
2.Oil and Gas
3.Chemical Processing
4.Chemical production and manufacturing facilities
5.Petrochemical plants
6.Power Generation
7.Steam and water systems in power plants
8.Cooling water systems
9.Nuclear power facilities
10.Marine and aviation applications
11.Pulp and Paper
12.Mining and Minerals
13.Aerospace and Defense
14.Wind turbine hydraulic systems
15.Solar thermal power plants

Description:
1.Body Material- Cast Iron and Cast Steel (LF2, A216, WCB, WCC, LCB, LCC, WC6, WC9), Ductile Iron, Stainless Steel [SS316, SS304, SS316L, SS904L, CF8, CF8M, F304, F316, F31L, F91), Duplex and Super duplex steel [F51, F53, F55] Forged Steel A105, A105N, F11, F22, F304, F316, F91] Alloy20, Hastelloy, ALBR.
2.Size- ½” – 80”
3.Class-150 – 2500; PN10 – PN-450
4.Ends-threaded, socket weld, butt weld, flanged, lug, wafer
